Product Description
Wilden Pump Air Kit
Kit, Air, H/2"/A/M/M
OEM Part Number: WIL-08-9992-99
Includes:
| Part Number | Description | Qty |
| 08-2003-01 | AIR VALVE ASSEMBLY,H800 | 1 |
| 08-2601-52 | GASKET, AIR VALVE, H800 | 1 |
| 08-3780-55-60 | SEAL SLIPPER 11.562 OD X .28 | 1 |
| 08-3790-55-60 | GUIDE RING | 2 |
| 08-2603-52 | ISOLATOR GASKET H800 | 1 |
| 08-3260-52-60 | GASKET, CENTER SECTION, H800 | 2 |
| 08-3300-99-60 | BUSHING ASSEMBLY, CNTR. SECT. | 2 |
| 08-3770-52-60 | O-RING, (10.475 X.275)BUNA,HP | 1 |
| 08-3020-52-60 | O-RING, (10.975 X.210)BUNA,HP | 1 |
| 08-7851-56-60 | SPRING, ACTUATOR PIN | 2 |
| 99-8310-99 | AIR SYSTEM 3ML GREASE PKT | 1 |
| 08-7852-56 | SPRING, DOME, PRES RELIEF H800 | 2 |
| 00-2870-52 | O-RING, (.612 X.103)BUNA | 8 |
| 08-3200-52 | O-RING, (.859 X.139)BUNA | 2 |
| 04-3875-50R | O-RING, (.176 X.070)POLYURETHA | 2 |
