2" Wilden Air Operated Double Diaphragm (AODD) Pump
XPS8/AAAAA/NES/NE/NE/0014
Part Number: 08-14500
| Series | Pro-Flo SHIFT |
| Product Model | XPS8 |
| Connection Outlet Size | 2" (51 mm) |
| Connection Inlet Size | 2" (51 mm) |
| Wetted Path Material | Aluminum |
| Construction | Clamped |
| Connection Type | BSP |
| Diaphragm Design | Standard |
| Add-On Feature | Standard Pump |
| Max Flow Capacity | 185 gpm |
| Ball Valves | Neoprene |
| Valve Seats | Neoprene |
| Diaphragms | Neoprene |
| Differential Pressure Ratio | 1:1 |
| Max Air Inlet Pressure | 125 psi |
| Max Solid Size | 1/4" (13 mm) |
| Lower Temperature Limit | 0 F |
| Upper Temperature Limit | 200 F |
| ATEX Certified | Yes |
Recommended Spare Parts
04-9993-99, Air End Repair Kit
08-9804-51, Wet End Kit
04-8340-99, Air Filter/Regulator Kit, 3/4"
