Grundfos TP-40-80/2 Direct Coupled In-Line Circulator, 3/4hp, BUBE Seal, Cast Iron, 208-230/460V, GF 40/43 Flange Mount
| Pump Size | TP40-80/2 | Motor HP | 3/4 |
| Type | Direct Coupled / Inline | Motor RPM | 3510 |
| Casing Material | Cast Iron | Voltage | 208-230/460 |
| Impeller | Stainless Steel | Phase | 3 |
| Shaft Seal | BUBE | Hertz | 60 |
| Connection Size | 1.50" flanged | Approvals | UL, CSA |
| Max Pressure | 145 PSI | Service Factor | 1.25 |
| Max Head | 26.2 ft. | Efficiency | 74% at full load |
| Max. Flow | 57.2 gpm | Weight | 68 lbs. |
Stock Item
