Product Description
P/N 5493-98
AMT® Stainless Steel Straight Centrifugal Pump
AMT® Stainless Steel Solids Handling End Suction Centrifugal Pumps are built for high flow and pressure applications, making them ideal for uses such as chemical processing, liquid transfer, cooling, pressure boosting, and dirty water handling. Their rugged stainless steel construction ensures durability and corrosion resistance, while the investment cast stainless steel closed impeller enhances performance and efficiency, allowing for the handling of solids up to 1/8″ in diameter.
Each pump features Viton® Type 21 mechanical seals and O-rings, providing broad chemical compatibility. The cast iron motor adapter ensures a stable and secure motor mounting. These pumps are not self-priming and require a flooded suction for operation.
| HP: | 2 |
| Phase: | 3 |
| Type: | TEFC |
| Frame: | 56J |
| VAC/60Hz | 230/460 |
| Material: | Stainless Steel |
| Seal Material: | Viton® |
| Full Load Amp: | 6/3 |
| Ship Weight: | 44 lbs |
| Quick Ship Pump: | Yes |
| Inlet Diameter: | 2" |
| Outlet Diameter: | 1.5" |
| Discharge Port Rotation: | 90 degree increments |
| Maximum Gallon Per Min: | 130 |
| Maximum Total Head: | 68 feet |
| Maximum Pressure: | 29 psi |
| Maximum Solids Handling: | 0.125" |
| Self Priming Pump: | Flooded Suction Only |
| Pump Housing Drain: | Yes |
| Housing Material: | Stainless Steel |
| Impeller Type: | Closed |
| Impeller Material: | Stainless Steel |
| Maximum Temperature: | 200 F |
| Port Type: | FNPT |
| Maximum Casing Working Pressure: | 150 psi |
| Dimensions: | L 14.5" x W 10.6" x H 7.8" |
