Product Description
P/N 369E-95
AMT® Centrifugal Pump
This line of AMT® Solids Handling End Suction Centrifugal Pumps are engineered for continuous-duty applications, including OEM, industrial, commercial, and general service tasks. They excel in functions such as circulation, chemical processing, liquid transfer, handling dirty water, and cooling.
These pumps are compact and built for durability, with various construction and seal materials to fit your specific needs. Their pull-from-rear design facilitates easy maintenance without disturbing the existing piping. The self-cleaning impeller effectively prevents clogging and can manage solids up to 1/8" in diameter.
Each pump is close coupled to Totally Enclosed Fan Cooled (TEFC) motors, though it's important to note that these pumps are not self-priming and require a flooded suction for operation.
| HP: | 2 |
| Phase: | 3 |
| Type: | TEFC |
| Frame: | 56J |
| VAC/60Hz | 230/460 |
| Material: | Cast Iron |
| Seal Material: | Buna-N |
| Impeller: | Stainless Steel |
| Full Load Amp: | 6/3 |
| Ship Weight: | 50 lbs |
| Quick Ship Pump: | No |
| Inlet Diameter: | 1.25" |
| Outlet Diameter: | 1" |
| Discharge Port Rotation: | 90 degree increments |
| Maximum Gallon Per Min: | 92 |
| Maximum Total Head: | 65 feet |
| Maximum Pressure: | 28 psi |
| Housing Material: | Cast Iron |
| Impeller Type: | Self Cleaning |
| Impeller Material: | Stainless Steel |
| Maximum Temperature: | 180 F |
| Port Type: | FNPT, NPT |
| Dimensions: | L 14.6" x W 8.8" x H 8.5" |
